Paper prototyping

012 min

Why paper prototyping exists

A design team that waits for working software to test its design learns the bad news late. By then the screens are coded, the data is connected, and every change means rework. Jakob Nielsen wrote in 2003 that the most common estimate puts the cost of a change before any code exists at one hundredth of the cost afterwards.

The obvious fix is to build a quick working version and test that. The Excel team tried it. They wanted to know whether people would like to drag and drop cells with the mouse, so they asked interns to build a prototype good enough for a usability test. It took them a whole summer to build, because it had to copy so much of the real program. The test showed that the feature was good. Joel Spolsky, who tells the story, adds that the programmer in charge then built the real feature in perhaps a week.

Why a working prototype is hard to keep cheap

A software prototype has to behave like the product, or the test tells the team nothing. A prototype that behaves like the product is close to being the product. The cost of the test then grows to match the cost of the thing being tested.

Paper breaks that link. A sheet only has to look right. A person supplies the behavior, so nobody writes code until the design has survived contact with a real user. That is the idea behind prototype testing in its cheapest form.

022 min

How a paper prototyping session works

Paper prototyping puts the interface on sheets and leaves the behavior to people. The team draws each screen, menu and dialog box on its own sheet or slip of paper. A participant receives a realistic task, such as finding the answer to a problem, and touches the sheets as if they were a screen. Where a button would be clicked, the participant points with a finger or pen.

Another team member plays the computer: when the participant touches a control, they put down the sheet that the software would show next. They do not explain the design and they do not hint. If the participant is lost, the loss stays visible, and that is the information the team came for.

Four roles make a session work:

1. 1

   Participant.

   A person who resembles a real user, not a colleague on the project.

2. 2

   Facilitator.

   The one person who talks to the participant, gives the task and asks what they expect to happen.

3. 3

   Computer.

   The team member who swaps sheets and slips, and says nothing about the design.

4. 4

   Observers.

   People who write down where the participant hesitates, goes the wrong way or says something is unclear.

Why a rough drawing gets frank answers

The method is also called low-fidelity prototyping. Fidelity means how closely a prototype matches the finished product in look and behavior. A low-fidelity prototype looks rough and relies on a person for its behavior. People tend to criticize a rough sketch more freely than a polished screen, because a sketch does not look finished. A participant who sees a drawing that took ten minutes is less worried about hurting a designer's feelings.

041 min

Where paper prototyping comes from

Teams did not always test this way. The method began in the mid-1980s and spread in the mid-1990s, when IBM, Honeywell, Microsoft and other companies adopted it. The accounts used for this entry give a period and a list of companies. They do not name one inventor or one founding paper, so none is credited here.

What changed the method's reach was a reference book. Carolyn Snyder, who ran paper tests at the consultancy User Interface Engineering, published her book Paper Prototyping in 2003. The same year, Nielsen wrote the article that is quoted above. Together they turned a technique that teams passed on by example into one with written instructions.

Its name hides a shift in thinking. Earlier prototypes were meant to show a finished-looking design to a client. A paper prototype is meant to be wrong in front of a user, so the team can find out where it is wrong.

052 min

What paper prototyping finds, and how well it works

A fair question is whether a test on a rough drawing finds real problems or only the obvious ones. Robert Virzi, Jeremy Sokolov and Demetrios Karis asked this at the CHI conference in 1996. They ran two experiments. In each one they built a low-fidelity and a high-fidelity version of the same product and compared the usability problems that each version revealed. Both experiments turned up nearly the same usability problems with the low-fidelity version as with the high-fidelity one.

These were two experiments on two kinds of product, so the result is strong evidence and not proof for every interface.

062 min

When paper prototyping does not fit

Paper still cannot show everything. Snyder lists rapid, subtle and complex interactions as weak spots, because the person playing the computer cannot respond as fast or as quietly as software.

Two more limits are practical. Paper prototypes can only be tested with the participant in the same room as the sheets, and they suit the early stage of a design more than the late stage. Once the questions turn to timing, motion or real data, a software prototype is the better tool.

072 min

Running a paper prototyping test

A team can run a first test with a short list of materials and a few roles. The steps below follow the order that sessions usually take.

1. Write the tasks first. Each task is a goal that a real user would have, such as finding help for a problem that is not on the list.
2. Draw one sheet for each screen the tasks need. Draw menus, dialogs and messages on separate slips, so the person playing the computer can place and remove them.
3. Rehearse with a colleague. The person who plays the computer should know where every sheet is before a participant arrives.
4. Recruit participants who resemble the real users. A teammate already knows how the design is meant to work.
5. Run the session. Ask the participant to say aloud what they expect and what they see, a habit called a think-aloud protocol. The facilitator asks questions and does not help.
6. Photograph the sheets and notes before tidying up, because paper gets lost.
7. Change the sheets and test again. The repeating cycle of test and change is the iteration cycle, and on paper each turn is cheap.

Comparing designs on paper

Paper also suits a comparison. A team can draw two or three versions of one screen and test them with the same tasks. Doing this on purpose is called parallel prototyping. Nielsen's three homepage mock-ups are an example of the material it needs: three drawings and a few participants.

082 min

Paper prototyping vs. nearby concepts

Several other methods share parts of paper prototyping, so a team can mix them up. The table sets four of them side by side.

The closest neighbor is Wizard of Oz. Both use a person to play the system. The difference is whether the participant knows. In paper prototyping the participant can see the person swapping sheets. In a Wizard of Oz test the participant believes the system is real.

Two other concepts sit close by. Experience prototyping tests what an experience feels like, often with physical props. A storyboard is a sequence of drawings that tells a story of use, and a participant does not operate it. A paper prototype is the one of these that a participant operates.
